The Yamaha DXS12 Mk2 is an active 12-inch subwoofer that comes equipped with a 1020w Class D amplifier alongside a 12-inch low-frequency driver, a digital signal processor, and a robust plywood polyurea coated enclosure that maintains a professional appearance.
- See full product description
The Yamaha DXS12 Mk2 is an active subwoofer that comes equipped with a large 12-inch woofer alongside a 1020w Class D amplifier that works effortlessly to deliver an impressive sound pressure level and a thick low-end extension to your sound. This subwoofer is perfect for small-medium sized club, bar, and music venues as well as mobile DJs, schools and colleges, entertainment facilities, and events productions.
| Yamaha DXS12 MK2 Subwoofer |
The highly-efficient 1020w Class D amplifier works effortlessly to deliver a huge sound pressure level of 136dB with a frequency response that ranges from 42 Hz – 150 Hz giving you a massive low-end extension. The 12-inch woofer comes fitted with a custom-designed 2.5-inch voice coil magnet that delivers a clear low-frequency bass response with minimal distortion at all times. A built-in D-XSUB digital signal processor provides you with a boost function for an even lower frequency response. This subwoofer is housed inside of a band-pass designed enclosure that effectively reduces unwanted vibrations and noise that could otherwise ruin your sound.
The DXS12 Mk2 comes housed inside of a super-durable road-ready enclosure that features a band-pass design ensuring unwanted vibrations and resonances will not ruin your sound. The plywood housing is coated in a Polyurea coating that is extremely damage resistant and protects the sub against scratches, bumps, and even severe weather conditions helping to maintain a professional appearance for years. The subwoofer comes fitted with dual pole mounts so you can mount a satellite speaker on top of the sub if necessary.
Yamaha DXS12 MK2 Active PA Subwoofer Key Features:
- 12" powered subwoofer with 1020W class-D power amplifier
- High-output 12” woofer with a band-pass design cabinet for superb bass response with a maximum 134dB SPL
- 42Hz-150Hz frequency range is ideal for small to medium-sized applications
- Built-in D-XSUB processing allows you to extend the frequency response even lower
- Plywood cabinet is durable and acoustically optimized for minimal distortion
- Cardioid mode for bass management onstage
- Selectable X-OVER (80/100/120 Hz)
- M20 and Ø35 mm dual pole sockets
Yamaha DXS12 MK2 Active PA Subwoofer Technical Specifications:
- Speaker type: 12" powered subwoofer, Band-pass type
- Frequency range (-10dB): 42 Hz - 150 Hz
- Components: 12" cone, 2.5" voice coil
- Output power: Dynamic: 1020W / Continuous: 800W
- Maximum output level (1m; on axis): 134 dB SPL
- I/O connectors: INPUT: XLR-3-31 x2 , THRU: XLR3-32 x 2(Parallel with INPUT)
- Processors: D-XSUB: BOOST,XTENDED-LF, OFF
- Cooling: Natural convection
- Power requirements: 100V – 240V, 50Hz/60Hz
- Power consumption: 100W
- Pole socket: 35 mm (depth 80 mm) & M20 (threaded depth 25 mm)
- Width: 400 mm (15.75")
- Height: 567 mm (22.32")
- Depth: 570 mm (22.44")
- Net weight: 30.0 kg (66.1lbs)
- Others, Material, Finish, Color: Meranti Plywood, Durable Polyurea Coating, Black
