The Pioneer S-DJ60X active reference monitor is no longer available, please click here to view our latest range of DJ speakers.
The Pioneer S-DJ60X active reference monitor is dependable, hard-wearing and formulates high-class sound output as would be expected from the Pioneer DJ brand. The individually built monitor has been designed to maximise sound performance, reduce surplus resonance and increase bass output.
- See full product description
The Pioneer S-DJ60X active reference monitor is dependable, hard-wearing and formulates high-class sound output as would be expected from the Pioneer DJ brand. The individually built monitor has been designed to maximise sound performance, reduce surplus resonance and increase bass output.
The speaker and bass reflex duct components are made up of strong and firm medium density fibreboard (MDF). To eliminate the redundant resonance and increase bass output the woofer units are attached to thick MDF inner baffles (5”-6” maximum thickness 30mm and 8” maximum thickness 33mm). The woofers contain soft dome tweeters permeated in magnetic fluid and aramid fibre made cones.
“Groove Technology”
The S-DJ60x monitor incorporates “Groove Technology” within its design. This is where grooves are inserted, in the bass reflex duct parts, so as to increase air flow and optimise the “Groove Technology”. This aids in efficiently releasing low frequency sounds from the front of the speaker unit. In addition, the front bass system emanates a powerful bass also from the face of the speaker. This feature is ideal to enhance the use of strong drum kick and bass sounds. Finally, round processing inside the ducts are useful in reducing noise, making the speaker ideal for dance music.
Driver
The driver has been designed with top-quality sound output and high response in mind. In order to accomplish this, the woofer cones are made from aramid fibre, which is highly durable and light, along with strong magnetic circuits that allow for balanced and broad high frequencies.
Class AB bi-amp
The newly designed Class AB bi-amp have been incorporated in both the tweeter and woofer units. This ensures the frequency response across all areas, and all the instruments that are played, are balanced.
“DECO” technology
The tweeters in this range of Pioneer active reference monitors have been installed with convex diffusers using “DECO” technology derived from TAD Labs’ TAD Pro TSM-2201-LR monitor speakers (used within professional studio set-ups). The convex diffuser separates the mid-range sound into right, left and upper sections which ensure 3D stereo and a broad sweet spot.
EQ Controls
The S-DJ60x speakers include an in-built equaliser (found at the rear of the unit) which allow the user to modify the high-pass level output. The user is able to change the high-frequency range in one-decibel increments (-2dB to +1dB) via the EQ control to suit their requirement.
Other features
The Pioneer S-DJ60x active reference monitors comes with three types of input ports: XLR, TRS and RCA, which allow connections to a variety of external sources e.g. PC/laptop, portable devices, DJ equipment etc. The speakers also include an “Auto Standby mode” which automatically turns the unit off if it hasn’t been used for a set period of time. Not only is this environmentally friendly but it is useful in saving power and is convenient to the user. Finally, if an input signal is detected the monitor will power back on.
Please note Speakers sold individually, not as pairs.
- Choose from 5-inch, 6-inch or 8-inch aramid fibre woofers
- 1-inch soft-dome tweeter with “DECO” convex diffuser from TAD Labs
- Front-loaded bass reflex system
- Highly rigid bass ducts with friction-reducing grooves
- Auto standby with an auto ON
- Class AB amplifiers
- Range of inputs
- High-frequency adjustment
- Available in black (5-inch also available in cool white)
- Speakers sold individually
Format: | Bi-amp 2-way bass reflex active monitor speaker |
Tweeter: | 1-inch soft-dome tweeter |
Woofer: | 6-inch aramid fibre woofer |
Frequency response: | 45 Hz~20 kHz |
Maximum SPL: | 113 dB |
Amplifier output (rated output): | Class A/B bi-amp 125W LF:90W (50 W) HF:35W (20 W) |
Input ports Balanced inputs: |
XLR×1、TRS(1/4 inch PHONE)×1 |
Input ports Unbalanced inputs: |
RCA×1 |
Input impedance: | 10kΩ |
Level control: | -∞dB~+6dB |
HF level adjust: | -2dB/-1dB/0dB/+1dB |
Power consumption (Standby mode): | 140 W (less than 0.5W) |
Maximum external dimensions (W×H×D: | 197mm×301mm×262mm |
---|---|
Unit weight: | 8.5kg |
Accessories included: | Power cord User’s manual |
