M-Audio M-Track 8x4M Audio/MIDI Interface (Archived)

Availability:Out of stock
SKU
M-Audio M-Track 8x4M Audio/MIDI Interface
£249.00

Seen it cheaper? We aim to match authorised UK dealers

Quick overview

Now Discontinued - Please Click HERE to view our latest music production gear.

The M-Audio M-Track 8x4M is a professional-quality USB audio/MIDI interface that is equipped with eight inputs and four stereo outputs with 24-bit/192kHz audio specifications for seamlessly recording excellent sounding music.

  • See full product description

Now Discontinued - Please Click HERE to view our latest music production gear.

The M-Audio M-Track 8x4M is a high-quality USB audio/MIDI interface that comes equipped with eight inputs alongside four outputs with all the connections needed to seamlessly record professional-quality 24-bit/192kHz recordings and features a heavy-duty metal chassis with a large central volume control. This audio/MIDI interface is ideal for both aspiring and professional music producers thanks to the excellent sound quality and range of input connections that allow you to record almost any audio source.

M-Track 8x4M Video


The M-Track 8x4M comes with transparent low-noise crystal preamps as well as pristine A/D converters that work to deliver the best audio performance for an interface in its class. This interface is fitted with four combo XLR/¼-inch TRS inputs alongside two ¼-inch line inputs and two ¼-inch instrument inputs that have been specially designed with a gain and impedance stage that work to provide you with the most accurate representation of your guitar or bass when plugged directly into the interface while MIDI in/outputs allow you to connect your controllers straight to the interface, freeing up your USB ports on your computer.

The 8x4M comes with a stereo pair of ¼-inch studio monitor outputs as well as two ¼-inch assignable outputs that allow you to connect multiple speakers to the interface so you can mix using various sets of speakers which lets you get the best mixdowns possible. When recording into your DAW, you can send two individual monitor mixes when using the two ¼-inch headphone outputs with independent source and level controls so you can send separate monitor mixes to musicians if needed. The M-Track comes with a premium Hi-Speed USB connection and is supplied with both USB-A and USB-C cables and offers zero-latency monitoring, so the recording process if more fluid than ever before.

Also supplied with this high-quality audio/MIDI interface is a complete software package that provides you with all the software required to create professional recordings straight out of the box. The included software provides you with a First M-Audio Edition of Pro Tools as well as Ableton Live Lite and a comprehensive package of effects plug-ins and virtual instruments designed to fulfill your production needs. The plug-in collection consists of Eleven Lite, 20 effects plug-ins, AIR’s Creative FX Collection, and AIR’s Virtual Instrument plug-ins with super-realistic drums, stunning synths, strings, percussion, and piano sounds.

M-Audio M-Track 8x4M Audio/MIDI Interface Key Features:

  • 24-bit/192kHz resolution for professional recording and monitoring
  • Hi-Speed USB connection with USB/Direct balance knob for zero-latency monitoring
  • Includes both standard USB and USB-C connection cables
  • 4 x XLR + ¼” TRS combo inputs, 2 x ¼” instrument inputs and 2 x ¼” line inputs
  • 2 x ¼” headphone outputs with independent source and level controls
  • Stereo ¼” main outputs; 2 x ¼” assignable auxiliary outputs
  • MIDI input/output for connecting virtually any external MIDI gear
  • Rugged metal chassis, large central control for easy volume adjustment

Included Software:

  • Pro Tools First - M-Audio Edition
  • Eleven Lite - Featuring high-quality guitar amp and FX models
  • Ableton Live Lite
  • AIR Music Technology Creative FX Collection - 20 world-class FX AU/VST plugins as made famous by Pro Tools
  • AIR Music Technology Xpand!2
  • AIR Music Technology Mini Grand
  • AIR Muisc Technology Strike
  • 2GB of Touch Loops Content

M-Audio M-Track 8x4M Audio/MIDI Interface Technical Specifications:

  • Power Adapter: 12VAC, 2A, center positive (included)
  • Dimensions (WxDxH cm): 8.22 x 25.9 x 18.9
  • Weight: 1.8Kg

Input Connectors

  • 4 x Combo XLR & 1/4” (6.35mm) TRS
  • 2 x 1/4” (6.35mm) TS instrument
  • 2 x 1/4” (6.35mm) TRS line inputs

Mic Inputs 1-4

  • Balanced XLR
  • Dynamic Range: 113dB (A-weighted)
  • THD+N: 0.001% (1kHz, +4dBu, -1dBFS)
  • Frequency Response: 20Hz – 20kHz (+/-0.2dB)
  • Preamp EIN: -137dBu (40Ω source, A-weighted), -129dBu (150Ω source, unweighted)
  • Max Input Level: +14dBu
  • Gain Range: 62dB

Line Inputs 1-4

  • Balanced 1/4" TRS
  • Dynamic Range: 113 dB (A-weighted)
  • THD+N: 0.001% (1kHz, +4dBu, -1dBFS)
  • Frequency Response: 20Hz – 20kHz (+/-0.1 dB)
  • Max Input Level: +30dBu
  • Gain Range: 61dB

Inst Inputs 5-6

  • Unbalanced 1/4" TS
  • Dynamic Range: 110dB (A-weighted)
  • THD+N: 0.001% (1kHz, +4dBu, -1dBFS)
  • Frequency Response: 20Hz – 20 kHz (+/-0.1dB)
  • Max Input Level: +16dBu
  • Gain Range: 59dB
  • Input Impedance: ~1MΩ

Fixed Line Inputs 7-8

  • Balanced 1/4" TRS
  • Dynamic Range: 113dB (A-weighted)
  • THD+N: 0.001% (1kHz, +4dBu, -1dBFS)
  • Frequency Response: 20Hz – 20kHz (+/-0.1dB)
  • Max Input Level: +17dBu

Output Connectors

  • 4 x 1/4” (6.35mm) TRS line outputs
  • 2 x 1/4” (6.35mm) TRS headphone outputs

Line Outputs 1-2

  • Balanced 1/4" TRS
  • Dynamic Range: 112dB (A-weighted)
  • THD+N: 0.002% (1kHz, -1dBFS)
  • Frequency Response: 20Hz – 20kHz (+/-0.2dB)
  • Max Output Level: +17dBu

Fixed Line Outputs 3-4

  • Balanced 1/4" TRS
  • Dynamic Range: 112dB (A-weighted)
  • THD+N: 0.002% (1kHz, -1dBFS)
  • Frequency Response: 20Hz – 20kHz (+/-0.2dB)
  • Max Output Level: +17dBu

Headphone Outputs

  • Stereo 1/4"
  • Dynamic Range 111dB (A-weighted, 32Ω Load)
  • THD+N: 0.002% (1kHz, -1dBFS, 10mW/channel into 32Ω load)
  • Frequency Response: 20Hz – 20kHz (+/-0.2dB)
  • Maximum Power Delivered: 160mW (<1% THD, 32Ω load)
  • Maximum Output Level: +15dBu (unloaded)
  • Impedance Range: 32Ω - 600Ω

Other Connectors

  • 1 x 1/8" (3.5mm) MIDI Input
  • 1 x 1/8" (3.5mm) MIDI Output
  • 1 x USB Type-C Port
  • 1 x Power Adapter
