Equinox Butterfly Quad MKII Sweeper Multi-Beam Lighting Effect

The Equinox Butterfly Quad MKII is a captivating multi-beam lighting effect that transforms any space with its dynamic display. This cutting-edge fixture features two sweeping LED bars, each equipped with four individually controllable narrow beams, delivering a total of eight sharp and intense beams that effortlessly cut through the air.

With a sharp 3° beam angle and eight powerful 10-watt RGB LEDs, the Butterfly Quad MKII enables intricate pixel mapping, allowing for the design of complex and visually stunning effects. Its impressive refresh rate of 4 kHz ensures smooth operation, while up to 36 DMX channels offer extensive control options.

Versatility is a key feature, with automatic, sound-active, and master/slave modes available for various performance settings. The unit allows for seamless dimming between 0-100%, providing smooth fades, as well as variable strobe speeds for more energetic and exciting displays. With an impressive tilt range of up to 160°, you’ll have the flexibility to create captivating light shows tailored to your event.

Designed for ease of use, the Butterfly Quad MKII features a hanging bracket for simple setup and trussing, along with a four-button menu that includes an LED display for straightforward control and DMX addressing. It also comes equipped with an IEC power input and output for easy power linking, as well as a 3-pin XLR DMX input and output for convenient connectivity.
