Korg Nu:Tekt NTS-2 Digital Synthesizer DIY Kit
Availability:Out of stock
SKU
Korg Nu:Tekt NTS-2
£169.00
Seen it cheaper? We aim to match authorised UK dealers
Quick overview
This product is now longer available, please click here to view the best alternative products.
The Nu:Tekt NTS-2 is a "Swiss army knife"-style DIY synthesizer for musicians. It is based on a 4-channel oscilloscope and contains a customizable waveform generator, spectrum analyzer, and tuner capabilities, making it an excellent addition to any studio
- See full product description
The NTS-2 synthesiser kit expands on the popularity of the NTS-1 synthesiser kit with this 4-channel oscilloscope and book combo, making it the ideal Xmas or Birthday present for any synthesiser fan. The NTS-2 is a one-stop shop for any synth enthusiast, combining a powerful oscilloscope, an FFT/spectrum analyzer, a dual waveform generator, and an internal tuner. The NTS-2 is a DIY kit that can be set up and ready to use in 10 minutes - no soldering necessary!
Long used to display voltage signals as waveforms, oscilloscopes provide quick visual feedback for your input signals. With four channels available, you may see up to four transmissions at the same time. You may also compare and overlay the four signals. The oscilloscope has several display settings to select from, each with a sharp and colourful colour screen. It also has dedicated buttons and clickable encoder knobs for quick and easy configuration and parameter navigation.
Spectrum analyser in real time with FFT mode
The NTS-2 has an effective real-time spectrum analyser in addition to the oscilloscope. The FFT (Fast Fourier Transform) mode allows you to study waveforms and signals that are represented by the sum of sine and cosine signals. This one-of-a-kind spectrum analysis is fantastic for sound design, allowing you to observe tonal shifts easily.
Precision tuner and dual waveform generator
The NTS-2's Wave Generator mode, equipped with two oscillators (each with separate outputs), allows you to generate a broad range of waveforms. There are sine, square, triangle, sawtooth, pulse, and noise waveforms provided, with the possibility to adjust the shape and phase of each waveform for further versatility. The various waveforms can be used as control voltage sources or within the audio range. They can also be activated as one-time impulses or configured to cycle continually. The waveform generator's versatility allows you to utilise the numerous waveforms as LFOs, envelopes, trigger control voltage generators, and even as a sound source.
Korg Nu:Tekt NTS-2 DIY Kit
- Four-channel oscilloscope
- Dedicated FFT (Fast Fourier Transform) mode with real-time spectrum analyser
- Flexible waveform generator with dual oscillators and various waveforms
- Sine
- Square
- Triangle
- Sawtooth
- Pulse
- Noise
- Waveforms shape and phase can be adjusted
- Waveforms can be used as LFOs, envelopes, triggers, control voltage generators and sound sources
- Variety of display modes to choose from
- Easy-to-use, precision tuner with multiple display modes
- DIY Kit – can be built and setup within 10 minutes (no soldering required)
- Compact, pocket-sized design
- Powered by 2 x AA batteries or via USB-C power supply
What’s Included
- NTS-2
- Side panels for NTS-2
- Stickers
Oscilloscope
- Modes:
- Single, Stereo (Input1L-INPUT1R, Input1L -
- Input2L, Input2L - Input2R), 4ch, XY(Lissajous, 2ch)
- Vert.: 10mV 5V/div, AC/DC MODE switchable
- Horiz.: 50us 1s/div
- Trigger: Auto, Rise, Fall, Single(rise), Single(fall)
Spectrum analyser
- Input: Mono (1L, 1R, 2L, 2R)
- Frequency Range: 20Hz 20kHz
Tone Generator
- Types: sine, square, triangle, saw, noise, pulse, envelope
- Frequency Range: 1Hz 10kHz, Hz/NOTE mode switchable, [1ms 10s,sec/BPM switchable(pulse, envelope mode)]
- Output: 10Vpp max, V/dB mode switchable
Tuner
- Modes: Needle, meter
- Input: Mono, Stereo (Input1L-Input1R, Input1L-Input2L)
- Calibration: 410-480H
General
- Weight (full bundle): 1.32 kg
- Dimensions (full bundle): 26.3 x 6.5 x 27.3cm
