Allen & Heath Xone 4D (Archived)

£1,249.00

Seen it cheaper? We match authorised UK dealers

Quick overview

Now Discontinued. Please Click HERE to few the latest alternatives.

  • See full product description
Deko Pay

0% Finance: From only £36.13 per month!

Now Discontinued. Please Click HERE to few the latest alternatives.

The Allen & Heath Xone 4D continues the seamless integration of computer-based digital media into the traditional DJ workspace

The Allen & Heath Xone 4D continues the seamless integration of computer-based digital media into the traditional DJ workspace, but with a further enhanced feature set. Combining a fully featured, high specification professional analogue DJ mixer with 105 MIDI controllers and 227 MIDI messages, a completely new, high-end, 96 kHz / 24-bit 20 channel Allen & Heath-designed USB 2.0 soundcard, the progressive XONE:4D has been developed in conjunction with some of the world’s most cutting-edge DJ/producers.

New features for the 4D include the new 20-channel USB 2.0 soundcard, a completely new BPM counter, assignable LFO with step VCF-filter and fresh new paint.

Mixer:

* 4 multi-input stereo channels: RIAA preamps for turntables on 3

inputs, (channel 4 is Line/Line)

* Soundcard output routing switches for each channel (1-2, 3-4, 5-6 &

7-8)

* 3-band total kill EQ: 6dB to off

* 2 FX sends: pre/post selection (internal on FX2)

* 2 stereo returns

* Headphone monitor with mix/cue control: 3.5mm and ¼” sockets

* 2 analogue VCF filters low-pass, band-pass, high-pass (can be

combined for more filter types), resonance frequency, and filter

‘on’ switch

* Filter assignable LFO with depth control and brand-new editable fader

step-filter function.

* Completely re-designed and functionally improved BPM detection



* Mic input: On XLR connector; gain control and 2-band EQ control

available: routable straight to soundcard.

* Power supply: High performance internal switch-mode supply

* RIAA: for THREE turntables (four via internal jumper link)

* Dual Rail VCA Cross Fader



USB 2.0 SOUNDCARD

* Totally new 20 channel 96 kHz / 24-bit soundcard connecting via

wide-bandwidth USB 2.0 (480Mbit/s)

* Uses 24 bit stereo Analogue to Digital converters and Digital to

Analogue converters (not lower spec CODECs)

* 10 in / 10 out (4 stereo in optical in / 4 stereo out optical out)

* No software configuration utility – all front panel switched.

* Soundcard inputs fed from Mic, FX2, FX1, Main Mix or from stereo

channels 1-4

* Sends - mix, FX, or individual analogue channels may be routed to PC

or digital outputs.

* New record output – FX2 RCA outputs can be switched to a RCA record

output.

* Drivers available for PC and Mac



MIDI CONTROLLER:

* NEW! 2 separate layers of MIDI controllers with control pickup

algorithm ensuring a smooth transition between layers.

* 227 MIDI control messages available from 105 separate MIDI controls

* 8 x 60mm linear faders

* 16 x detented rotary pots

* 10 rotary encoders,

* 50 switches,

* 2 custom jog wheels with 4 micro switches

* 8 illuminated push switches

* Xone:4D is compatible with any PC software that has MIDI assignable

functions: for instance, lighting controller or visual effects programs
